J23-63W Open power press

Technical data: 1.Rated pressure:630KN; 2.Slide travel(Adjustable range):0-100mm; 3.Travel times:40t/min; 4.Max. die set height:310mm; 5.Die set height adjustment:80mm; 6.Slide block centre to the frame:310mm; 7.worktable size:F-B*L-R:570*860mm; 8.Dimension of slide block bottom surface:F-B*L-R:340*400mm; 9.Size of the handle hole:diameter*depth:50*80mm; 10.Inclinable angle of body:30 degree; 11.Motor type/power:Y132M-4/7.5KW; 12.Overall size:L*W*H:1940*1502*2870mm; 13.Weight:5800KG.
